Xtreme XS800BX Portable Explosives/Narcotics Trace Detector

The Explosive /Narcotics Trace Detector is a new generation portable photoionization product made based on the advanced high-resolution photoionization lon Mobility Spectrometry(PIMS). The Explosive/Narcotics Trace Detector, characterized by quick detection, high sensitivity, low power consumption, small size, light weight, portable design, easy maintenance and high adaptability for different conditions /requirements, is suitable for detecting black powder as well as all exploders specified by the International Civil Aviation Organization accurately and widely used for safety inspection, national defense/ security and public safety works in important places such as airports and stations etc. 。

Items	Specification
Technology	High resolution PIMS
	Explosives (only appropriate for explosive test mode):
	Various military, civil and homemade explosives, etc;such
	as the black powder, ammonium Nitrate (AN).trinotrototuol
Detectable	(TNT),dinitrotoluene(DNT),trinitrophenyh.methylnitramine(
Explosives	Tetryl), pentaerythritol tetranitrate (PETN), gun powder, NG
	explosive, hexogen (RDX), Semtex explosive and C4, etc;
	New samples can be added to two detection types according to requirements
Detectable Narcotics	Narcotics (only appropriate for Narcotics test mode): cocaine(COC),heroin,morphine,Amphetamine,tetrahydroc annabinol(THC),dehydrogenation,ephedrine

	methamphetamine, and ecstasy, etc. New samples can be added to according to requirements	two detection	types
Sampling	Test paper wipe picking
Sensitivity	ng level
Alarming pattern	Audio message+screen information
Analyzing time	≤ 2 s
Warning up time	＜ 20 min
Rate of false alarm	≤1%
Detectable rate	≥ 99%
Working condition	-10 ℃～ 55 ℃  Relative humidity 45% ～ 85%
Power supply	220V AC 50-60Hz/ Lithium battery power supply
Power adapter	Imput: 220V/AC 50-60Hz ； output: 19V/DC
Battery parameter	Lithium    battery               14.8V/4400mAh supply,no less than 2h	Continuous	power
Weight	3.82 Kg
Overall dimension	450mm(L) ×160mm(W) ×200mm(H)
Technical standard
